Continuous welding helps to prevent dripping of wet materials. Formed smooth edge around top and pouring lip for safety and strength.
Extended sides prevent side-wise scattering of material. Strong, easy-to-operate latching mechanism.
These hoppers are designed to be easily handled by forklifts and typically include a mechanism that allows them to tip and dump their contents without manual intervention.
Capacity
Volume Capacity: Usually measured in cubic yards (cy) or cubic feet (cf). Typical capacities range from 0.25 to 5 cubic yards.
Weight Capacity: Indicates how much weight the hopper can handle, typically measured in pounds (lbs) or kilograms (kg). This can vary from 1,000 to 10,000 lbs or more.
Dimensions
Overall Dimensions: Length, width, and height in inches or feet. The dimensions of the hopper affect how much space it will take up and what material it can hold.
Fork Pocket Size: The size of the openings on the bottom of the hopper through which the forklift forks are inserted. Fork pocket dimensions typically include height, width, and center-to-center spacing.
Dumping Mechanism
Automatic Self-Dumping: Describes whether the hopper automatically dumps its load when it is tilted or a release mechanism is activated by the forklift operator.
Manual Release: Some hoppers require the operator to manually activate the dumping mechanism by pulling a lever or cable.
Material Construction
Body Material: Usually made from heavy-duty steel (e.g., 10-gauge or 12-gauge). Galvanized steel or painted steel options are available for corrosion resistance.
Finish: Powder-coated or painted finishes are common for rust resistance and durability.
Load and Tilt Angle
Tilt Angle: The maximum angle at which the hopper can be tilted for dumping, usually around 45 to 90 degrees.
Load Center: Refers to the balance point of the hopper when full. This is important for stability during dumping operations.
Safety Features
Safety Chain: Prevents the hopper from sliding off the forklift forks during transport.
Latch or Locking Mechanism: Ensures the hopper stays closed until it's ready to dump.
Return Mechanism: After dumping, some hoppers automatically return to their upright, locked position for ease of use.
Mobility Options
Casters: Some self-dumping hoppers come with wheels or the option to add casters for easier mobility.
Base Type: Some models feature reinforced bases or hopper stands for added stability.
Self-dumping forklift hoppers are versatile tools used in various industries for efficient handling, transport, and disposal of materials.
